O.E.M. Replacement Tensilite® Titanium Valves for Husqvarna® & KTM® Various 450's 2013-2018

•  Dimensionally identical to O.E.M. valves while offering many advantages
•  One piece forged Titanium alloy offers uninterrupted grain flow
•  Superior tensile strength and stability at and above operating temperatures
•  Every surface either fully CNC machined or precision ground
•  Super-finished stem allowing for Formula 1 level coating consistency
•  100% Chromium Nitride (CrN) PVD coated
•  Material and workmanship that provide outstanding durability and performance
•  Competitive pricing allowing for a value conscious rebuild

​​

To learn more about other Kibblewhite® Husqvarna® and KTM®  parts and accessories, go to
Husqvarna® Various 450's 2014-2018
KTM​® Various 450's 2013-2018 ​​

Lightweight Racing Beehive Spring Kit and Components for Can Am® Maverick™ / X3 (900cc Triple Engines) 2017-'20 / Rotax® ACE 900cc Triple Engines 2014-'19

By taking advantage of the latest development in valve spring wire chemistry and manufacturing techniques, KPMI® has developed ovate wire Beehive style springs that will live and perform at a high level in Can Am® applications. By coupling these developments with strict KPMI® design protocols and employing multiple design simulation and FEA analysis software, we were we able to overcome the torsional stresses unique to ovate wire springs that previously limited their operating parameters. KPMI® Beehive Springs are progressively wound using Kobe Super-Clean chrome silicon based wire that is heat treated and shot peened. KPMI® uses its tightly toleranced, FEA designed hardened Titanium retainers in these applications to ensure correct assembly height and resist keeper pull through. KPMI® made OEM replacement seals are included for a more complete performance valvetrain solution.


These Engine Builder valve guides have been designed with the price conscious builder in mind. Expect the same exacting KPMI® tolerances, but with a reduced toughness / wear-ability when compared to premium C630 Nickel Aluminum Bronze valve guides. The softer Manganese guides are easily reamed, and then can be delicately finished with our high quality ball hones. Now, with any battery operated or electric drill you can ream and hone manganese valve guides in less time and in the absence of expensive honing equipment required to properly size tough Nickel Bronze guides. Additionally, these guides have been designed to be compatible with our uniquely designed guide installation and removal tools. A relief in the seal detail allows for driving force to be applied without causing deformation in harmful areas.


All KPMI® Black Diamond™ Stainless steel valves are impregnated by a special German process to a depth of .002", with a surface build up of .0002". This Black Diamond process improves wear properties, reduces friction, and provides resistance to corrosion and wear that is superior to chrome and nickel electrolysis plating. Each valve is designed using Finite Element Analysis software, and profiles are tested on our computerized flow bench. Black Diamond Valves are lightweight, strong, one piece forgings with profiles that provide excellent flow characteristics.


To learn more about this Kibblewhite® Beehive Spring Kit and other valvetrain related components, go to

Can Am® Maverick / X3 (900cc Triple Engines) 2017-2020

Rotax ACE 900cc Triple Engines 2014-2019


Tech Bulletin- Superseded Kawasaki® and Suzuki® Valves

KPMI® has several Kawasaki® and Suzuki® valve designs whereas we have selected a proprietary material and heat treatment process that enhances the durability of the valve face to retard valve face recession.  For several years now, this material and heat treatment process was coupled with the KPMI® Black Diamond™ surface treatment.  During the heat treatment stage of manufacturing, the Black Diamond™ coating would come under attack and suffer oxidation and corrosion, leaving a new valve looking used.  Although this combination of processes did achieve a superior stainless one piece valve that would prove to have a highly durable valve face, the valve heads had an unaesthetic appearance (see Figure 1 and 2).  Recently, the KPMI® engineering department completed design reviews for all valves with these issues.  The solution was to move away from the KPMI® Black Diamond™ treatment and introduce the well-recognized and proven KPMI® White Diamond® coating and then post process after heat treatment to leave the head of the valve in a beautiful polished stainless finish (see Figure 1 and 2). We hope you are as excited as we are to provide you with these enhanced valve designs that we will be introducing in a superseding fashion over the next few months.

​​​

To learn more about  the first round of the updated superseded part numbers, go to

Kawasaki®  KLX / KFX 400  2001-2006

Suzuki®  LT-Z / D-RZ 400  2000-2017
Suzuki®  RM-Z450 2005-2006

S&S H.T. Steel Cylinder Head Dowels for Various Harley-Davidson®

•  S&S “ Oversized” Dowel for 4" to 4-3/8" Cylinders
•  Black Oxide Coated for Corrosion Resistance
•  Heat Treated Steel
•  Cone Dowel for 1948-’05 Various HD® Applications
•  See Description Below for Special Design Features

​​

To learn more about other Kibblewhite® Various Harley- Davidson®  parts and accessories, go to
Harley-Davidson® Panhead 1948-1965

Harley-Davidson® Shovelhead 74" 1966-1977

Harley-Davidson® Shovelhead 80" 1978-1983
Harley-Davidson® Evolutions 1984-1999

Sportster 883cc  1986-2017

Sportster 1200cc 1988-2017

Solid Carbide Reamers

•  KPMI® solid carbide reamers provide long life and repeatability
•  Solid carbide, 6-flute design, share the chip load and ease the sizing operation
•  Extra-long-pilots for stability and alignment
•  Ideal for: Manganese Bronze or Cast Iron
•  The KPMI® reamer diameters offered, provide recommended and optimum valve-guide-clearances


KPMI® Carbide valve guide reamers are manufactured from Solid Carbide and then heat treated and ground. All KPMI® reamers are ground to: +/- .0002”.  KPMI® carbide reamers are straight-flute and have a 6-flute design. The pilot portion of KPMI® reamers are 1.0” to 1.5” long.  Insert the pilot into a guide that you intend to size.  Using a hand held drill, apply honing oil or ATF before and during reaming a guide.  KPMI® reamers have been specifically designed for Manganese Bronze valve guides and Cast Iron. Do not attempt to use these reamers to size C630 Nickel Aluminum Bronze guides.  Also, once a reamer is used on Cast Iron, it’s not advisable to then use it on a bronze guide.



To learn more about these Kibblewhite®  Solid Carbide Reamers and other valvetrain related components,
go to
Tools and Components Section.

Solid Carbide Reamers

•  KPMI® solid carbide reamers provide long life and repeatability
•  Solid carbide, 6-flute design, share the chip load and ease the sizing operation
•  Extra-long-pilots for stability and alignment
•  Ideal for: Manganese Bronze or Cast Iron
•  The KPMI® reamer diameters offered, provide recommended and optimum valve-guide-clearances


KPMI® Carbide valve guide reamers are manufactured from Solid Carbide and then heat treated and ground. All KPMI® reamers are ground to: +/- .0002”.  KPMI® carbide reamers are straight-flute and have a 6-flute design. The pilot portion of KPMI® reamers are 1.0” to 1.5” long.  Insert the pilot into a guide that you intend to size.  Using a hand held drill, apply honing oil or ATF before and during reaming a guide.  KPMI® reamers have been specifically designed for Manganese Bronze valve guides and Cast Iron. Do not attempt to use these reamers to size C630 Nickel Aluminum Bronze guides.  Also, once a reamer is used on Cast Iron, it’s not advisable to then use it on a bronze guide.



To learn more about these Kibblewhite®  Solid Carbide Reamers and other valvetrain related components,
go to
Tools and Components Section.

Figure 1

High Chrome Seats

•  18-22% Chromium for resistance to abrasion, corrosion, and deformation
•  1-2% Nickel content, which lends to corrosion-resistance and toughness
•  Machined from solid bar stock and ground to exacting tolerances
•  The alternative to Powder Metal
•  Machines as a continuous chip
•  Use KPMI® “High Chromium Seats” for your next gasoline or diesel engine rebuild


 To learn more about these Kibblewhite® high chrome seats and other valvetrain related components,  go to

Tools and Components Section.

​12  |  3  |  4  |  5  |  6  | 7 | 8 | 9

Lightweight Racing Beehive Spring Kit and Components for Husqvarna® & KTM® Various 450's 2013-2018

By taking advantage of the latest development in valve spring wire chemistry and manufacturing techniques, KPMI® has developed ovate wire Beehive style springs that will live and perform at a high level in Husqvarna® and KTM® applications. By coupling these developments with strict KPMI® design protocols and employing multiple design simulation and FEA analysis software, we were we able to overcome the torsional stresses unique to ovate wire springs that previously limited their operating parameters. KPMI® Beehive Springs are progressively wound using Kobe Super-Clean chrome silicon based wire that is heat treated and shot peened. KPMI® uses its tightly toleranced, FEA designed hardened Titanium retainers in these applications to ensure correct assembly height and resist keeper pull through. The hardened steel basewashers included in these kits are designed to locate the spring and control lateral movement.


We choose to use the copper based C63000 nickel-aluminum bronze as a material to make our bronze valve guides because of its ideal characteristics for the application. The 5% nickel content provides superior resistance to wear, and the approximately 80 percent copper content delivers outstanding heat conductivity. KPMI® guide profiles are designed to have minimal effect on the airstream while maintaining critical cross sectional thickness in high temperature areas, which promotes high performance and endurance.


All KPMI® Black Diamond™ Stainless steel valves are impregnated by a special German process to a depth of .002", with a surface build up of .0002". This Black Diamond process improves wear properties, reduces friction, and provides resistance to corrosion and wear that is superior to chrome and nickel electrolysis plating. Each valve is designed using Finite Element Analysis software, and profiles are tested on our computerized flow bench. Black Diamond Valves are lightweight, strong, one piece forgings with profiles that provide excellent flow characteristics.


To learn more about other Kibblewhite® Husqvarna® and KTM®  parts and accessories, go to

Husqvarna® Various 450's 2014-2018

KTM​® Various 450's 2013-2018 ​​

Cam Tower Bolts for Various Suzuki® Applications

•  Manufactured from heat treated, high tensile steel
•  Exceeds OEM specifications dimensionally and by grade
•  Designed for repeated removal and installation…these bolts are tuff!
•  Treated with Black Oxide, for corrosion resistance
•  Can be purchased in kits and by application or bulk




To learn more about other Kibblewhite® Various Suzuki® parts and accessories, go to
Suzuki®  GDXR 600 / 700 2004-2018
Suzuki®  GDXR 1000 2005-2017

Suzuki®  RM-Z250 2010-2017

Suzuki®  RM-Z450 2008-2018

Suzuki®  Hayabusa 1999-2017

Tools / Components, Cam Tower Bolts

Black Diamond™ Valves for Various Honda® 750's 1979-1983

•  Material and workmanship for desired advantages
•  One piece forged EV8-SS offers uninterrupted grain flow for head stability
•  Tufftride® coated for a high durability, low friction impregnated surface finish
•  “Super-Finished” stem allows for Formula 1 level coating consistency
•  Dimensionally controlled production tolerances for outstanding consistency
•  Every surface is either CNC machined or ground as top quality valves should be
•  Swirl polished or CNC machined profiles are Flow Bench tested for optimization
•  Street, Strip or Track. You are choosing extreme durability and performance

In order to provide complete coverage of the vintage Honda® DOHC line-up, we are proud to announce the CB750 / CBX Black Diamond™ Stainless Steel Intake and Exhaust Valves. These valves are an OEM upgrade that combine vintage style with the modern design attributes that define our standards here at KPMI®. Our Black Diamond™ Valves have been proven to outlast OEM and provide the performance you desire in your motorcycle.

​​

To learn more about other Kibblewhite® Various Honda® 750's parts and accessories, go to
Honda®  CB750 1979-1983
Honda® CBX 6 Cylinder  1979-1983​​

High Performance Pushrods for Various BSA® and Triumph® Applications

•  KPMI® Pushrods are designed with thin-wall Chrome Moly tube for increased stiffness over O.E.M.
•  Male and female endpieces are made from hardened steel and offer increased wear resistance
•  Blank Pushrod Kits come with one female endpiece pressed into the body and loose endpieces specified in the kit
•  Custom length pushrods available upon request


Note: Blank Pushrod kits (sets of 2 and 4) can be machined to desired length and assembled by KPMI® for a flat fee of $120.00. Orders can be placed by using the Custom BSA® Pushrod Order Form found on our website at www.kpmi.us/forms.html.


​To learn more about these Kibblewhite® High Performance Pushrods, or other valvetrain related components for the various models,  go to

BSA® A50 1966-1970

BSA® A65 1971-1972

BSA® B25 1968-1971

BSA® B44 RB 1967-Earlier

BSA® B44-SqB 1968-1970

BSA® B50 1971-1973

Triumph® Pre-Unit 500/ 650 1751-1962

Triumph®  650/ 750 1963-1983

High Performance Blank Pushrods

Bronze & Cast Iron Racing Tappet Block for Triumph® 500/ 600/ 750 1946-1983

•  Precision ground OD and reamed bores allow for easy installation exceeding OEM tolerances
•  Bores are sized with a piloted reamer and finished with a ball hone to achieve proper running clearance and surface
   finish after the tappet block is installed
•  Bronze tappet blocks are designed for high performance applications by taking advantage of excellent heat transfer
   capabilities, high lubricity, and durability
•  Cast iron tappet blocks are machined from a proprietary cast iron material with the same design features as our
   bronze version, providing a more affordable alternative


To learn more about other Kibblewhite® Various Triumph® parts and accessories, go to
Triumph ®  Pre-Unit 500 & 650's 1951-1962
Triumph ®  Pre-Unit 500 & 650's 1951-1962



Figure 2

Valve Guide Installation & Removal Tools for Suzuki® GSX-1300R™ Hayabusa™ 1999-2017

•  Machined to properly fit KPMI® Hayabusa valve guide designs
•  Extra-long handles provide ergonomically grooved gripping area and the ability to work in tough to reach situations
   Guide installation tool is designed to register on uniquely designed seal relief minimizing guide deformation on the seal       end, ensuring proper height above the head without guess and check measuring as seen in Figure (1)
•  Guide removal tool allows the user to drive any 5mm guide with a 10mm outer diameter through lengthy guide bores

   thanks to its added length below the gripping area shown in Figure (2)
•  Driver material is a high strength bronze purposefully selected for its shock absorption capabilities allowing for

   comfortable use as well as compatibility with cast and bronze guides




To learn more about these Kibblewhite® Valve Guide Installation & Removal Tools, or other valvetrain related components,  go to  Suzuki GSX-1300R Hayabusa 1999-2017 Section

Figure 1             Figure 2

Top End Service Kits - Stainless Conversion for Various Honda® and Yamaha® Applications

ALL KIT CONTENTS
•  High Compression Racing Piston with Coated Skirt (with rings and pin)
•  Top End Gasket Kit (Head Gasket, Base Gasket, Exhaust Gasket, Cam Chain Tensioner  Gasket, Valve Stem Seals, Cylinder Head Drain Seal)
•  Std. Black Diamond™ or White Diamond® Stainless Valves
•  Lightweight Racing Spring Kit (Titanium Retainers, Dual Springs, H.T. Steel Basewashers)

FEATURES
•  Designed specifically for the performance demands of popular racing MX Bikes and Quads.
•  Pistons designed to maintain the stock compression after the effects of the dished stainless valves
•  2618 Alloy Fully CNC Machined Piston with performance skirt coating
•  Black Diamond™ and White Diamond® Stainless Steel Conversion system significantly increases valve durability
•  Lightweight Racing Spring Kit Compatible with high performance cams
•  All of the gaskets, rings, pins and seals required for a top end rebuild

IMPORTANT NOTE: The piston, rings, valves and pin clips in this kit are designed to work together as a system. They are NOT COMPATIBLE with O.E.M. components and should ONLY be used with the components in this KPMI® Top End Service Kit.

​​

To learn more about other Kibblewhite® Various Honda® and Yamaha® parts and accessories, go to
Honda®  CRF 450R 2002-2008
Honda®  CRF 450X 2005-2017

Honda®  TRX 450R 2004-2005

Honda®  TRX 450R / ER 2006-2014

Yamaha® YZ450F 2003-2005 / WR 450 2003-2006​​

​Yamaha® YZ450F 2006-2009 / WR 450 2007-2015

Turbo Valve Kit for Polaris®, RZR™ XP 1000 & XP Turbo, 2015-2021

•  1 piece forging with White Diamond® hard chrome stems for impervious wear resistance
•   Inconel® 751 exhaust valves designed to outperform in the most extreme forced induction or racing applications
•   Flow bench tested to optimize intake and exhaust profiles
•   100% Quality Controlled


Kit includes:
4pcs.
White Diamond® Std. Intake Valve
4pcs.
White Diamond® Inconel® Std. Exhaust Valve


The Turbo Valve Kit is specifically designed for Turbo applications using our 1-Pc forged “Super Alloy” Inconel® 751 exhaust valve that retains mechanical properties and corrosion resistance at elevated temperatures.  The exhaust valve is paired with a 1-Pc White Diamond® Stainless Intake for superior performance and longevity.  Together this valve kit provides the performance for boosted applications at a competitive selling price.

​​

To learn more about other Kibblewhite® Polaris® RXR XP 1000 & XP Turbo parts and accessories, go to
Polaris®  RZR XP 1000 & XP Turbo 2015-2021

Steel Dowels for Harley-Davidson® M-8 2017-2021

•  Black Oxide Coated for Corrosion Resistance
•  Rounded End Installed in Cylinder or Case
•  Tapered End Installed in Head or Cam-Support Cover
•  Designed as HD® M8 OEM Replacement
•  Can Also Be Used as Multipurpose Dowel
•  See Dimensions for Fitment

​​

To learn more about other Kibblewhite® Harley- Davidson® M-8 parts and accessories, go to
Harley-Davidson® M-8 2017-2021
